Anti-Vibration Tables — DIT-E / DIT-AM Tables
SHOCK RESISTANT/ANTI-VIBRATION TABLE WITH ELASTOMERIC ISOLATION Series DIT-E Dynemech Anti Vibration Tables - Series DIT-E are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. The Vibrations are isolated using Double-Layered Dp Elastomeric Sheets. These Anti-Vibration Tables have a Granite Surface Plate with Grade-00/Grade-1 accuracy for very precise measuring accuracies. The passive vibrations from nearby motors and other heavy machinery is reduced by 65-70%. The vibration isolation efficiency of these tables can be further increased by placing more than 2 layers of our Dp insulation Sheets. Five layers of DP exhibits a natural frequency of 7-8 Hz. which damps most of the incoming frequencies above 20 Hz. APPLICATIONS : The Vibration Isolated Table (VIT) finds usage in critical areas where reading accuracy of instruments like: Balances, Galvanometers, Electronic Microscopes and Atomic Absorption Spectrophotometers, is affected by Vibrations.
Specifications
| Model | Length (mm) | Width (mm) | Height (mm) | Surface Plate Thickness (mm) | Table Load Capacity (Kg) | Natural Frequency (Hz) |
|---|---|---|---|---|---|---|
| DIT-E/01 | 500 | 500 | 800-1000 | 80 | upto 250 | 7 to 8 |
| DIT-E/01/s1 | 630 | 630 | 800-1000 | 80 | upto 250 | 7 to 8 |
| DIT-E/02 | 750 | 500 | 800-1000 | 80 | upto-450 | 7 to 8 |
| DIT-E/03 | 900 | 600 | 800-1000 | 100 | upto-1250 | 7 to 8 |
| DIT-E/04 | 1000 | 800 | 800-1000 | 150 | upto-1250 | 7 to 8 |
| *Special table sizes and designs can also be ordered as per client's requirements | — | — | — | — | — | — |
| SHOCK RESISTANT/ANTI-VIBRATION TABLE WITH AUTO LEVELLING PNEUMATIC VIBRATION MOUNTS - DIT-AM | — | — | — | — | — | — |
| Dynemech anti vibration table DIT-AM has natural frequency in the range of 1.5-2 Hz along with self-levelling feature. Available self-levelling is +0.01mm and +0.1mm varients with minimum setting time. Membrane air springs damps most of the incoming vibration above 3Hz. Application : Metrology equipments, High precision weighing balances, TGA, digital hardness testers, High resolution microscopes, surface roughness testers, etc. | — | — | — | — | — | — |
| Model | Length (mm) | Width (mm) | Height (mm) | Surface Plate Thickness (mm) | Table Load Capacity (Kg) | Natural Frequency (Hz) |
| DIT-AM/01 | 500 | 500 | 800-1000 | 80 | upto 400 | 1.5 to 2 |
| DIT-AM/01/s1 | 630 | 630 | 800-1000 | 80 | upto 400 | 1.5 to 2 |
| DIT-AM/02 | 750 | 500 | 800-1000 | 80 | upto 850 | 1.5 to 2 |
| DIT-AM/03 | 900 | 600 | 800-1000 | 100 | upto-1150 | 1.5 to 2 |
| DIT-AM/04 | 1000 | 800 | 800-1000 | 150 | upto-1250 | 1.5 to 2 |
| *Special table sizes and higher loads can also be designed as per client's requirements | — | — | — | — | — | — |
