Wedge Mounts — Series DBSP

Name: Wedge Mounts — Series DBSP
Brand: Dynemech Systems

Power Presses, Stamping Machines, Shearing Machines, Punching Machines. For machines with high vertical impact.

12 models Load: 1300–36000 Kg

Specifications

Model	Load Capacity Kg/pc	Length (L) mm	Width (B) mm	Height (H) at mean position (mm)	d (mm)	e (mm)	BOLT (mm)	h (mm)	D (mm)	Adjst. Range (mm)
DBSP1-m	1300	115	115	59	110	24	M16	19	110	+4/-4
DBSP2-m	2250	150	150	65	150	23	M18	20	150	+5/-5
DBSP3-m	4000	200	200	65	200	27	M20	22	200	+6/-6
DBSP4-m	5000	200	250	85	200	27	M20	22	200	+7/-7
DBSP5-m	8000	250	320	90	250	55	M24	28	250	+8/-8
DBSP6-m	8500	300	400	90	300	50	M24	32	300	+9/-9
DBSP1-h	3970	115	115	59	110	24	M16	19	110	+4/-4
DBSP2-h	6750	150	150	65	150	23	M18	20	150	+5/-5
DBSP3-h	12000	200	200	65	200	27	M20	22	200	+6/-6
DBSP4-h	15000	200	250	85	200	27	M20	22	200	+7/-7
DBSP5-h	24000	250	320	90	250	55	M24	28	250	+8/-8
DBSP6-h	36000	300	400	90	300	50	M24	32	300	+9/-9

Power Presses, Stamping Machines, Shearing Machines, Punching Machines. For machines with high vertical impact.

Very Heavy and long bed machines, long machining centres, planners etc.
